DESCRIPTION

Telescopic doors bring you the gift of uniqueness and give you the system which is unlike any other traditional old-fashioned one. Employing TL profile set and kit, you will be able to transform your normal sliding door into a telescopic one. Due to having four moveable leaves instead of two, you can enjoy much more convenience in a limited space.

View in larger size
Standards TL240
DIN18650
EN16005
EN60335
EN ISO 13849
EU low voltage directives
EU EMC directives
ISO 9001
TÜV approved In Process
CE conformity
1.000.000 cycles durability test
Technical Data
Opening width – double leaves 900 – 3000mm
Opening width – four leaves 1800 – 4000mm
Max leaf weight, double 2 x 150kg
Max leaf weight, four 4 x 100kg
Operator height 155mm
Operator depth 226mm
Opening speed Variable up to 1.1 m/s

(Four leaves)

Closing speed Variable up to 1.1 m/s

(Four leaves)

Hold-open time 0 – 30s
Ambient temperature -15 to +50°C
Protection class IP20
100% German-made operator kit
Control unit origin Leesys GmbH, a part of Siemens Enterprise Communication
Gear motor origin German by Dunkermotoren
Track profile Stainless Steel Aluminium
Anti-noise rubber profile
Gear motor power 100W
Second motor for emergency opening
Dual gear motor and control unit set for master and slave concept
No. of hanger per leaf 2
External protected power supply
Power supply power 230V/28V,240VA
Back-up battery for emergency opening
Possibility to use safety sensors with testing signal
24V DC output for external accessories
Power lock
Lock monitoring
Possibility of using more software and hardware options by using DEAP device (optional)
Read-out error memory with error codes (with digital programme switch)
Programmable output (optional)
Programmable input (optional)
Possibility of using mechanical key switch (optional)
Possibility of using Digital programme switch (optional)
Possibility of using electro-mechanical lock (optional)
Maximum operation cycles with 2.2 Ah backup battery (optional) 400
Maximum operation cycles with 7.2 Ah backup battery (optional) 1000
Frames
Thermal break THB
Thermal break TBS
UTS
Saturn
Frameless
