DESCRIPTION

This model gives your facade a magnificent look like no other entrance. Offering a wider opening, Deutschtec curved sliding door is a perfect choice when you desire great ease of passage in hectic times.

Standards CR240
DIN18650 YES
EN16005 YES
EN60335 YES
EN ISO 13849 YES
EU low voltage directves YES
EU EMC directives YES
ISO 9001 YES
TÜV approved   –
CE conformity YES
1.000.000 cycles durability test YES
Technical Data
Opening width – single panel 800 – 2000mm
Opening width – double panel 1000 – 3000mm
Max leaf weight, single 200kg
Max leaf weight, double 2 x 150kg
Operator height 155mm
Operator depth 160mm
Opening speed 100 – 550mm/s
Closing speed 100 – 500mm/s
Hold-open time 0 – 30s
Ambient temperature -15 to +50°C
Protection class IP20
100% German-made operator kit y
Control unit origin Leesys GmbH, a part of Siemens Enterprise Communication
Gear motor origin German by Dunkermotoren
Track profile Stainless Steel
Anti-noise rubber profile YES
Gear motor power 100W
Second motor for emergency opening
using dual motor gear and control unit set for safe emergency opening and double life time operation
No. of hanger per leaf 2
external protected power supply YES
Power supply power 120VA
back-up battery for emergency opening
possibility to use safety sensors with testing signal YES
24V DC output for external accessories YES
power lock YES
lock monitoring YES
possibility of using more software and hardware options by using DEAP device (optional) YES
read-out error memory with error codes (with digital programme switch) YES
programmable output (optional) YES
programmable input (optional) YES
Possibility of using mechanical key switch YES
Possibility of using Digital programme switch YES
Possibility of using electro-mechanical lock YES
Possibility of using HSML lock YES
Possibility of using Battery YES
maximum operation cycles with 2.2 Ah backup battery 400
maximum operation cycles with 7.2 Ah backup battery 1000
Frames
Thermal break THB NO
Thermal break TBS YES
UTS NO
Saturn NO
Frameless NO
